2026 Mercedes-Benz GLE: Suspension and Steering Systems

Meta: Learn how the 2026 Mercedes-Benz GLE suspension and steering systems improve comfort, handling, and control for everyday driving

The Mercedes-Benz GLE uses multiple suspension and steering configurations across its trim range. The systems vary by model grade, engine type, and AMG designation. Each configuration supports different priorities such as ride comfort, load control, or performance response.

Front and Rear Suspension Architecture

All GLE models share a common basic layout.

Front Suspension

• Independent four-link front suspension
• Coil springs or air springs, depending on trim
• Stabilizer bar

The four-link front axle design separates longitudinal and lateral forces. This structure supports steering precision and wheel control.

Rear Suspension

• Independent multi-link rear suspension
• Coil springs or air springs, depending on trim
• Stabilizer bar

The multi-link rear axle allows separate control of camber and toe angles under load. This setup supports stability and comfort.

Standard Suspension System

Most non-AMG GLE trims use a steel-spring suspension as standard equipment.

Key Features

• Steel coil springs
• Passive shock absorbers
• Fixed ride height

This system provides conventional damping control without adaptive adjustment. Ride height remains constant and does not change based on speed or load.

The steel-spring setup is typically found in:

• GLE 350 4MATIC
• GLE 450 4MATIC

This configuration maintains mechanical simplicity while preserving the independent front-and-rear architecture.

AIRMATIC Air Suspension System

AIRMATIC air suspension is available on select trims.

System Components

• Air springs at all four wheels
• Adaptive damping system
• Ride height adjustment capability
• Self-levelling function

The air suspension replaces steel springs with air-filled bellows. The system can adjust damping characteristics and vehicle height electronically.

Ride Height Control

AIRMATIC allows height variation depending on:

• Drive mode selection
• Vehicle speed
• Load condition

At highway speeds, the system can lower the vehicle to reduce aerodynamic drag. Under certain off-road conditions, the suspension can raise the body to increase ground clearance.

E-ACTIVE BODY CONTROL System

E-ACTIVE BODY CONTROL is available on specific plug-in hybrid and higher trims equipped with air suspension.

System Structure

• Fully active hydraulic suspension
• 48-volt electrical architecture
• Individually controlled suspension forces at each wheel

Unlike passive or semi-active systems, this system actively controls spring and damping forces independently at each wheel.

Functional Characteristics

• Active roll stabilization
• Pitch and dive reduction
• Individual wheel load adjustment

The system can counteract body roll during cornering and reduce front-end dive under braking. It operates through electronically controlled hydraulic actuators integrated into the air suspension struts.

E-ACTIVE BODY CONTROL requires the 48-volt onboard system found in certain electrified models.

AMG Suspension Configuration

AMG versions of the GLE use performance-oriented suspension systems.

AMG RIDE CONTROL

AMG GLE 53 and AMG GLE 63 models use AMG RIDE CONTROL suspension.

Key elements include:

• Air suspension with AMG-specific calibration
• Adaptive damping
• Sport-tuned components

The AMG system adjusts damping force across multiple drive programs. Calibration differs from non-AMG AIRMATIC systems to reflect performance requirements.

AMG ACTIVE RIDE CONTROL (Where Equipped)

Certain AMG variants may use an active stabilization system integrated into the suspension. This system manages roll forces without traditional mechanical anti-roll bars.

Damping Technology Across Trims

Suspension damping varies by configuration.

Passive Damping

• Fixed shock absorber settings
• No electronic adjustment

Found in steel-spring base trims.

Adaptive Damping

• Electronically adjustable shock absorbers
• Multiple drive modes

Available with AIRMATIC and AMG RIDE CONTROL systems.

Fully Active Damping

• Individual wheel force control
• Hydraulic actuation

Available with E-ACTIVE BODY CONTROL.

Steering System Overview

All GLE models use rack-and-pinion steering with electric power assistance.

Electric Power Steering (EPS)

Key characteristics:

• Speed-sensitive steering assist
• Variable steering ratio (on select trims)
• Integration with driver assistance systems

Electric power steering adjusts assist levels based on vehicle speed. At low speeds, steering effort reduces. At higher speeds, assist decreases to support stability.

Rear-Axle Steering System

Rear-axle steering is available on select GLE trims.

System Operation

• Rear wheels steer up to several degrees
• Opposite direction to front wheels at low speeds
• Same direction as front wheels at higher speeds

At low speeds, opposite-direction steering reduces turning circle diameter. At higher speeds, same-direction steering enhances lane change stability.

Rear-axle steering integrates with the electronic stability system and drive mode selection.

Steering Ratio and Response

Steering ratio may vary depending on trim and equipment.

• Standard models: conventional ratio
• AMG models: performance-oriented calibration
• Rear-axle steering models: variable ratio effect

The electric system allows adjustment through drive modes such as Comfort, Sport, or Sport+ in AMG variants.

Integration With Drive Modes

Suspension and steering systems connect to drive mode selection.

Drive Mode Effects

• Damping stiffness adjustment
• Ride height modification (air suspension models)
• Steering assist variation
• Stability control thresholds

Drive modes alter system behaviour electronically rather than mechanically. Steel-spring models have limited suspension variation compared to air suspension or active systems.

Ground Clearance Variation

Ground clearance depends on suspension type.

• Steel-spring models: fixed clearance
• AIRMATIC models: adjustable clearance
• E-ACTIVE BODY CONTROL models: fully variable height control

Air suspension models can increase ride height for uneven surfaces. At highway speeds, automatic lowering can occur.

Off-Road Suspension Features

On models equipped with air suspension:

• Height adjustment for terrain
• Self-levelling under load
• Electronic traction system integration

Steel-spring models do not include ride height adjustment.

Load Levelling Function

AIRMATIC and E-ACTIVE BODY CONTROL systems include automatic load levelling.

Function Description

• Detects rear load changes
• Adjusts air pressure in rear springs
• Maintains consistent ride height

This function preserves suspension geometry and headlamp aim when cargo weight increases.

System Differences Across Trims

The GLE suspension and steering systems vary by trim level.

Steel-Spring Models

• Four-link front suspension
• Multi-link rear suspension
• Passive damping
• Electric power steering

AIRMATIC Models

• Air springs
• Adaptive damping
• Ride height control
• Electric power steering

E-ACTIVE BODY CONTROL Models

• Fully active hydraulic system
• Individual wheel force control
• 48-volt system integration
• Electric power steering

AMG Models

• AMG RIDE CONTROL air suspension
• Sport calibration
• Performance steering setup
• Optional rear-axle steering

2026 GLE Questions and Answers

What front suspension design does the 2026 GLE use?

• The GLE uses an independent four-link front suspension.

Which system allows ride height adjustment?

• AIRMATIC and E-ACTIVE BODY CONTROL allow ride height adjustment.

What type of steering system is standard across the lineup?

• All trims use rack-and-pinion steering with electric power assistance.

Which suspension system uses hydraulic control at each wheel?

• E-ACTIVE BODY CONTROL uses individually controlled hydraulic actuators.

Do all GLE models include rear-axle steering?

• No. Rear-axle steering is available only on select trims.
